Spray Rating Tester
Spray Rating Tester to determine the surface wetting resistance of fabrics, which may or may not have been given a water-resistant or water-repellent finish. Spray Rating Tester complies with AATCC 22, ISO 4920, EN24920, etc. Our Spray Tester is your best choice when you do spray test
Category: Fabric & Garments
Description
Model:Â TF160
Brand: TESTEX
Application
Spray Rating Tester, to determine the surface wetting resistance of fabrics, which may or may not have been given a water-resistant or water-repellent finish.
Spray rating tester consists of a metal framework allowing distilled water to be sprayed through a nozzle onto a test specimen at 45° and 150mm below the nozzle.
Rated 0 out of 5
0 reviews
Rated 5 out of 5
0
Rated 4 out of 5
0
Rated 3 out of 5
0
Rated 2 out of 5
0
Rated 1 out of 5
0
Only logged in customers who have purchased this product may leave a review.
Specifications
- Nozzle 19 holes of Di 0.9mm
- Angle of holder 45°
- Holder 150mm, 150mm below the nozzle
- Measuring Cup 250m
Weight
12kg |
Dimensions
Width: | 260 mm | Length: | 220 mm | Height: | 550 mm |
Standards
ISO 4920 | AATCC 22 | BS EN 24920 | BS 3702 |
M/S P23 | M/S P133 | NEXT 23 |
