Thickness Gauge

Digital Thickness Gauge, to determine the thickness of various woven and knitted fabrics under a certain pressure. Digital Thickness Tester complies with ISO5084, ISO9073, ISO9863, etc. We are professional Digital Thickness Tester suppliers.

Description

Model: TF121

Brand: TESTEX

Application

Digital Thickness Gauge, to determine the thickness of various woven and knitted fabrics under a certain pressure. Automatic lifting up and down avoiding manual operation error by presetting pressing time for 10s or 30s, available with two unit mode in mm and inch.

0 reviews
0
0
0
0
0

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Specification

  • Digital display
  • Range of thickness: 0.01~25mm or 0.001~25mm
  • Measuring accuracy: 0.01mm or 0.001mm
  • Lowering speed of pressing-foot: 1.72 mm/s
  • Area of pressing foot: 100mm2, 2000mm2, 2500mm2, 10000mm2
  • Load Weight: 20cN, 100cN, 200cN, 500cN, 2000Cn
  • Pressing duration: 10s, 30s

Weight

70 kg

Power/Air Source

220 V50 Hz40 W

Dimension

Length:410 mmWidth:160 mmHeight:300 mm

Standards

ISO 5084ISO 9073ISO 9863GB 3820
FZ/T 01003
