Taber Abrasion Tester
Model: YG(B)522G
Brand: fatinovision
Taber Abrasion Tester, which often referred to as “Taber Abraser” or “Taber Abrasion Machine”, is a testing machine to test the wear resistance of fabrics, leather, and more. It complies with ASTM D3884/D3389/D4060, ISO 5470,etc. We provides Taber Abrasion Tester for sale with competitive price.
Description
【Related Standards】:
ISO5470-1, ASTM D3884, DIN53863.2
【Technical Specifications】:
- Diameter of the working disc: Ф115mm
- Dimensions of the grinding wheel: Diameter Ф50mm, Thickness 13mm
- Counting range: (0 – 99999) times
- Rotational speed of the working disc: (20 – 99) r/min
- Pressing force: Self-weight of the press sleeve 250cN
Weight 1: 750cN
Weight 2: 250cN
Weight 3: 125cN
- Power supply: AC220V ± 10%, 50Hz
- Dimensions: (520 × 370 × 360) mm
- Weight: 45kg
