Moisture Management Tester
Moisture Management Tester, to measure the dynamic liquid transport properties of textiles such as knitted and woven fabrics in three dimensions.
Description
Model: TF128
Brand: TESTEX
Moisture Management Tester, to measure the dynamic liquid transport properties of textiles such as knitted and woven fabrics in three dimensions.
Absorption Rate – Moisture absorbing time of the fabric’s inner and outer surfaces.
One-way Transportation Capability – Liquid moisture one-way transfer from fabric’s inner surface to outer surface
Spreading / Drying Rate – Speed of liquid moisture spreading on fabric’s inner and outer surfaces
MMT permits the measurement of the following indexes
- Wetting Time Top / Bottom (WTT / WTB)
- Absorption Rate Top / Bottom (TAR / BAR)
- Maximum Wetted Radius Top / Bottom (MWRT / MWRB)
- Spreading Speed Top / Bottom (TSS / BSS)
- Accumulative One-Way Transport Capacity (R)
- Overall Moisture Management Capacity (OMMC)
Only logged in customers who have purchased this product may leave a review.
Specifications
- MMT Analysis Software is offered
- Interface USB 1.1/2.0
- Power Supply 110V~230V 50Hz/60Hz 0.5 A
- Operation Temp & R. H. 18°C to 40°C, 20% to 80% (non-condensing)
- Pump On Time 20 sec
- Test Solution Conductivity – 16 mS± 0.2 mS
- Upper Weight 4.65N ± 0.05
Weight
| 60 Kg |
Dimensions
| 320 x 200 x 320mm (L x W x H) |
Standards
| AATCC 195 |
