Thickness Gauge
Digital Thickness Gauge, to determine the thickness of various woven and knitted fabrics under a certain pressure. Digital Thickness Tester complies with ISO5084, ISO9073, ISO9863, etc. We are professional Digital Thickness Tester suppliers.
Description
Model:Â TF121
Brand: TESTEX
Application
Digital Thickness Gauge, to determine the thickness of various woven and knitted fabrics under a certain pressure. Automatic lifting up and down avoiding manual operation error by presetting pressing time for 10s or 30s, available with two unit mode in mm and inch.
Only logged in customers who have purchased this product may leave a review.
Specification
- Digital display
- Range of thickness: 0.01~25mm or 0.001~25mm
- Measuring accuracy: 0.01mm or 0.001mm
- Lowering speed of pressing-foot: 1.72 mm/s
- Area of pressing foot: 100mm2, 2000mm2, 2500mm2, 10000mm2
- Load Weight: 20cN, 100cN, 200cN, 500cN, 2000Cn
- Pressing duration: 10s, 30s
Weight
| 70 kg |
Power/Air Source
| 220 V | 50 Hz | 40 W |
Dimension
| Length: | 410 mm | Width: | 160 mm | Height: | 300 mm |
Standards
| ISO 5084 | ISO 9073 | ISO 9863 | GB 3820 |
| FZ/T 01003 |
